AM29F200BB-90SI

2 Megabit, CMOS 5.0 Volt-only, Boot Sector Flash Memory, SOP, Low power consumption

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.80~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.80~2.50

PartNumber:: AM29F200BB-90SI

Brand:: Advanced Micro Devices - AMD | Pack: SOP | D/C: 00+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Jessi's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-18

From Other Seller

Part Number:AM29F200BB-90SI
US $1.80 - 2.50
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AM29F200BB-90SI is a 2 Mbit, 5.0 Volt-only Flash memory organized as 262,144 bytes or 131,072 words. The 8 bits of data appear on DQ0–DQ7; the 16 bits on DQ0–DQ15. The AM29F200BB-90SI is offered in 44-pin SO and 48-pin TSOP packages. The device is also available in Known Good Die (KGD) form. For more information, refer to publication number 21257. The AM29F200BB-90SI is designed to be programmed in-system with the standard system 5.0 volt VCC supply.

Parametrics

AM29F200BB-90SI absolute maximum ratings: (1)Storage Temperature Plastic Packages:–65℃ to +150℃; (2)Ambient Temperature with Power Applied:–55℃ to +125℃; (3)Voltage with Respect to Ground: VCC:–2.0 V to +7.0 V, A9, OE#, and RESET# :–2.0 V to +12.5 V, All other pins:–0.5 V to +7.0 V; (4)Output Short Circuit Current:200 mA.

Features

AM29F200BB-90SI features: (1)5.0 V for read and write operations; (2)Minimizes system level power requirements; (3)High performance:Access times as fast as 45 ns; (4)20 mA typical active read current (byte mode); (5)28 mA typical active read current for (word mode); (6)30 mA typical program/erase current; (7)1 μA typical standby current; (8)One 16 Kbyte, two 8 Kbyte, one 32 Kbyte, and three 64 Kbyte sectors (byte mode); (9)One 8 Kword, two 4 Kword, one 16 Kword, and three 32 Kword sectors (word mode); (10)Supports full chip erase; (11)Top or bottom boot block configurations available; (12)Embedded Algorithms; (13)Minimum 1,000,000 write/erase cycles guaranteed; (14)Pinout and software compatible with single-power-supply flash; (15)Superior inadvertent write protection; (16)Detects program or erase cycle completion; (17)Hardware method for detection of program or erase cycle completion; (18)Supports reading data from a sector not being erased.
