Product Summary

The NJM2538V is a video amplifter with 75ohms drivers, which includes LPF and BPF of both Y and C system.

Parametrics

NJM2538V absolute maximum ratings: (1)Supply Voltage: 7.0V; (2)Power Dissipation, PD: 300mW; (3)Operating Temperature Range: -20 to 85℃; (4)Storage Temperature range, Tstg: -40 to 125℃ .

Features

NJM2538V features: (1)Operating Voltage: V1=4.5 to 5.3V; V2=2.7 to 5.3V; (2)Low Power, 110mW; (3)Internal Black and White 2 Level Imposer; (4)Internal SDC Interface; (5)Bipolar Technology.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
NJM2538V-TE1
NJM2538V-TE1

NJR

Video ICs Amp with 75ohm Drvr

Data Sheet

0-2000: $1.20
2000-6000: $1.15
NJM2538V-TE2
NJM2538V-TE2

NJR

Video ICs Amp with 75ohm Drvr

Data Sheet

0-2000: $1.20
2000-6000: $1.15
NJM2538V-TE1#
NJM2538V-TE1#


IC VIDEO AMP W/DRIVER 20-SSOP

Data Sheet

0-2000: $1.30
