Product Summary
The PHN603S is a flat-base type, insulated package. The applications of the PHN603S are: General purpose inverter; servo drives and other motor controls.
Parametrics
PHN603S maximum ratings: (1)Collector-Emitter Voltage VCES when VD = 15V, VCIN = 15V; (2)Collector Current ±IC when TC = 25℃; (3)Collector Current (Peak) ±ICP when TC = 25℃; (4)Collector Dissipation PC when TC = 25℃; (5)Junction Temperature Tj when TC = 25℃.
Features
PHN603S features: (1)Adopting new 5th generation IGBT (CSTBT) chip, which performance is improved by 1μm fine rule process. For example, typical Vce(sat)=1.5V @Tj=125℃; (2)I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation. upper and lower arm of IPM.; (3)New small package. Reduce the package size by 10%, thickness by 22% from S-DASH series.
